| Brand Name : | Sysolution |
| Model Number : | RP1 |
| Certification : | FCC，CE certification |
| Price : | Negotiation |
| Payment Terms : | T/T,PayPal |
| Supply Ability : | 30 units per week |
| Delivery Time : | 2-3 working days |
| Parameter name | Parameter values |
| Cameras | |
| Appearance | Gun type |
| Sensor type | 1/2.7-inch CMOS |
| Pixels | 4 MP |
| Maximum resolution | 2688×1520 |
| Scan method | Progressive scanning |
| Electronic shutter | 1/3s~1/100000s (manually or automatically adjustable) |
| Minimum Illumination | 0.002 Lux (in color mode); 0.0002 Lux (in B&W mode); 0 Lux (when fill light is on). |
| Signal-to-noise ratio | ＞56dB |
| Maximum fill light distance | 80m (IR video monitoring distance) 30m (warm light video monitoring distance) 10m (warm light face detection distance) |
| Fill light | 2 (infra-red lights) 2 (warm lights) |
| Footage | |
| Type of lens | Fixed focal length |
| Lens interface | M12 |
| Lens focal length | 3.6mm |
| Lens aperture | F1.6 |
| Field angle | 84° horizontal x 44° vertical x 100° diagonal |
| Aperture control | Fixed aperture |
| Close up distance | 0.8m |
| Smart Items | |
| General behavioral analysis | Objects left behind; removal of objects |
| Heat maps | Support |
| Professional Intelligence | |
| Profound mental | Support |
| Perimeter precautions | Tripwire intrusion; area intrusion; fast movement (support for human-vehicle classification and accurate detection); wandering detection; people gathering; parking detection |
| Face capturing | Support |
| Face capturing | Support face detection; tracking; preference; capture; reporting the best face capture; face enhancement, face exposure; face keying area can be set: face, single inch photo; real-time capture, preference capture, quality first three capture strategy; face angle filtering function; preference length can be set |
| Headcount | Support the counting of people entering, leaving and passing, and display and output daily, monthly and yearly statistical reports; support the counting of people in the area statistics, 4 rules configuration, statistics and linkage alarm for the limited number of people in the area and detention time; support queue management, 4 rules configuration, statistics and linkage alarm for the limited number of people in the queue and queue time |
| Intelligent Search | With Smart NVR, it can realize secondary intelligent retrieval, analysis and condensed playback of event footage |
| Video | |
| Video compression standards | H.265；H.264；H.264H；H.264B；MJPEG (auxiliary stream support only) |
| Intelligent Coding | H.264: support; H.265: support |
| Video frame rate | 50Hz Main stream (2688×1520@25fps), secondary stream (704×576@25fps), third stream (1280×720@25fps) 60Hz Main stream (2688×1520@30fps), secondary stream (704×480@30fps), third stream (1280×720@30fps) |
| Video bit-rate | 3Kbps ~ 8192Kbps |
| Day and night conversion | ICR automatic switching |
| Backlight compensation | Support |
| Strong light suppression | Support |
| Wide Dynamic | 120dB |
| White balance | Automatic; Natural light; Street light; Outdoor; Manual; Zone customization |
| Gain control | Manual; Automatic |
| Noise reduction | 3D noise reduction |
| Default code stream at default resolution | 2048kbps(2688×1520) |
| Fogging function | Support |
| Image Flip | Support |
| Corridor model | 90°/270° (supported at 1080P resolution and below) |
| Mirroring | Support |
| Privacy Shield | 4 pieces |
| Audio | |
| Built-in MIC | Support |
| Built-in speakers | Support |
| Audio compression standards | G.711a；G.711Mu；PCM；G.726；AAC；G722.1；MPEG2-Layer2 |
| Audio sampling rate | 8 KHz；16 KHz；32 KHz |
| Alarm | |
| Alarm incidents | No SD card; Insufficient SD card storage; SD card error; Network disconnection; IP conflict; Illegal access; Motion detection; Video masking; Tripwire intrusion; Area intrusion; Fast movement; Item left behind; Item moved; Wandering detection; People gathering; Parking detection; Scene change; Audio anomaly detection; Voltage detection; Face detection; SMD; Number of people in area statistics; Stranding alarm; Number of people statistics; Number of people anomaly detection; Number of people in queue; Queuing time; Security anomaly; Light alarm; Sound alarm (with 21 languages to choose, support user-defined language import) |
| Network | |
| Network Interface | 1 x (RJ-45 network port, supports 10M/100M network data) |
| Network protocols | IPv4；IPv6；HTTP；HTTPS；TCP；UDP；ARP；RTP；RTSP；RTCP；RTMP；SMTP；FTP；SFTP；DHCP；DNS；DDNS；QoS；UPnP；NTP；Multicast；ICMP；IGMP；NFS；PPPoE；802.1x；SNMP |
| Access standards | ONVIF(Profile S/Profile G/Profile T)；CGI；GB/T28181(dual national standard)；GA/T1400；AIPS 4.0 cloud platform； |
| Preview the maximum number of users | 20 (total bandwidth: 64M) |
| Storage functions | AIPS 4.0 cloud platform；FTP; SFTP; Micro SD card (supports up to 256G); NFS |
| Browser | IE support: IE9 and above; Google support: Chrome 42 and above; Firefox support: Firefox 48.0.2 and above |
| Docking platform | NVR5X,NVR4X,IVSS,EVS,DSS7016D-I,SmartPSSPlus,Yunrui,AIPS 4.0 cloud platform |
| Network Security | Stream Encryption; Firmware Encryption; Configuration Encryption; Digest; WSSE; Account Lockout; Security Logging; IP/MAC Address Filtering; X.509 Certificate Generation and Import; syslog; HTTPS; 802.1x; Trusted Boot; Trusted Execution; Trusted Upgrade |
| Function | |
| Image settings | Brightness; Contrast; Sharpness; Saturation; Gamma |
| OSD information overlay | Time; access; geo location; pictures; face statistics |
| Video mode | Manual Recording; Video Detection Recording; Timed Recording; Alarm Recording Recording Recording priority from highest to lowest is Manual Recording > Video Detection Recording > Timed Recording |
| Max. Micro SD card | 256GB |
| Restore default | Supports one-click restoration of default configuration |
| User Management | Supports maximum 20 users |
| Safe Mode | Authorized username and password; MAC address binding; HTTPS encryption; IEEE 802.1x; network access control |
| Low light level | star-grade |
| Other functions | Light alarm; audible alarm; intelligent fill light |
| Power supply | |
| Operating voltage | DC12V(±30%)；POE+ (802.3at) |
| Power supply method | DC12V/POE |
| Power consumption | Basic power consumption: 4.2W (DC12V); 5W (POE); Maximum power consumption (H.265+IR+Intelligent+Wide Dynamic+Alarm Speaker White): 11.1W (DC12V); 13.4W (POE) |
| Environment | |
| Operating temperature | -40℃~+60℃ |
| Working humidity | ≤95% |
| Protection class | IP67 |
| Structure | |
| Housing material | Metal + plastic |
| Product size | 218.3mm×108.2mm×96.0mm (L x W x H) |
| Package size | 307mm×155mm×143mm (L x W x H) |
| Net weight | 669.5g |
| Gross weight | 865.0g |
| Mounting method | Wall-mounted; suspended; riser-mounted; cross-mounted |
| Power supply | Not standard |
| Footage | Standard |
|
|
