Sysolution android control card Y60C

Product introduction:

Y60C allow to publish programs and control display through PC,mobile phone,Pad and other user terminals, supports wireless transmission and access to cloud platform release, easy to achieve remote display cluster control; The hardware and software design fully considers the user deployment, operation and maintenance scenarios, making deployment easier, operation more stable, and maintenance more efficient; With safe and stable function design, it can save space and reduce wiring for users. It can be used in small carrying scenes such as car screen, small traffic screen, community screen and light pole screen.

Y60C uses Qualcomm MSM8909 platform solution. The MSM8909 processor is manufactured using the 28nmLP CMOS process, and the quad-core frequency is 1.1GHz. The memory supports 1GB + 8GB (compatible with 2GB + 16GB) LPDDR3. The chip is a highly integrated product, can support GSM, WCDMA, TD-SCDMA, EVDO, TDD-LTE, FDD-LTE and other standards.

Features:

1. The information release platform shall provide a copy and seal of the third-level filing certificate of the Ministry of Public Security information system security;

2. Information release platform material examination and approval of audiovisual programs transmitted through information network for filing, copy and seal;

3. Passed the national quality inspection stable qualified product certificate, provide the copy and seal;

4. Dual gigabit network port output, can be used as a backup, to ensure the stability of picture transmission;

5. Support the 485 interface through the external eight elements of environmental sensor R68, display environmental information, no need for secondary development;

6. External Lora synchronization module is supported to ensure the synchronization of multiple screens；

7. Support two remote power off, one control screen switch, one control street lamp switch.

Functions:

1. Support FCC, CE certification；

2. Lora wireless calibration multi-screen synchronization；

3. Onboard WiFi module, realize wireless communication；

4. support AP mode, Station mode；

5. Support secondary development, support remote cluster control of cloud platform；

6. Built-in Web Sever, support for local web page production, support PC, iPhone, Pad or other user terminals to publish program and control screen, remote cluser publish program, control screen and monitor screen status；

7. Strong processing performance, 4 core processor, main frequency 1.2ghz, support 1080P video hard decoding, 1GB running memory;

8. 8GB internal storage space, 4GB available to users;

9. When the user terminal connects to the WiFi hotspot provided by Y60C, the default SSID is ”SN“, and the default password is ”12345678“；

10. Support 4G network(The standard CAT4),4G is currently available only in China；

11. Support GPS timing/check time；

12. Dual network ports with super load capacity, 720 pixels(width)*1280(height) pixels resolution；

13. Support dual network ports loop backup；

14. Automatically adjust display brightness;

15. Support to broadcast programs according to the program list;

16. Through the management system, you can centrally set the timing switch, volume, and brightness;

17. Support USB camera；

18. Support NTP precise automatic time correction;

19. Supporting software: AIPS4.0 cloud platform.
